  • PayPal, Visa, Mastercard, Discover
  • You’ll receive a download link instantly in your e-mail
  • Plans are in PDF format for convenient printing on 8.5 x 11 paper
  • You don’t have to decide what size plans to buy because you get all 21/31 sizes
  • These plans have been written in great detail specifically for you – the first time shed builder
3 column top

  • 3/12, 4/12, 5/12 roof pitch options
  • 2, 3 1/2, 5 1/2 inch overhang
  • 21 sizes from 8×4 to 12×20
  • Single and double doors
  • Single top plates
  • Wall studs and roof trusses 24 inch O.C.
  • Cheapest and easiest to build

Buy Now 3 column top

$7.95

3 column top

Includes 3/12, 6/12 & 12/12 roof pitches

  • 3/12, 6/12 and 12/12 roof pitches
  • 12 inch overhang
  • 31 sizes from 8×4 to 16×32
  • 8, 10, 12, 14 & 16 ft widths
  • Single and double doors
  • Floor studs 12 inch O.C.
  • Wall studs 16 inch O.C.
  • Roof trusses 16 inch O.C.
  • Double top plates
  • Includes 48 inch loft the length of the shed with an optional gable end door
  • Frame for pre hung doors and windows

Buy Now 3 column top

$9.95

3 column top

Updated to include:
10 Larger sizes,
Overhang &
Crows Beak
Original
Also includes original version without overhang

  • Gambrel style barn roof
  • 12 inch overhang (option)
  • 31 sizes from 8×4 to 16×32
  • 8, 10, 12, 14 & 16 ft widths
  • Crows Beak (option)
  • Single and double doors
  • Floor studs 12 inch O.C.
  • Wall studs 16 inch O.C.
  • Roof trusses 16
    or 24 inch O.C.
  • Double top plates
  • Includes full width loft
  • Frame for pre hung doors and windows

Buy Now 3 column top

$9.97

Feedback:

“Just wanted to compliment you on the plans/video’s for the shed. I’m about half way thru and things are working out very well. Everything has been very straight forward. Would have been much harder without your plans and instruction. Thanks so much.”

“Thanks for your shed plans.  I think I looked at every major plan outlet online and otherwise and I found your plans to be the most straightforward, easy to read and use, and easy to customize without fuss. I was worried with the name cheapsheds.com, but this shed I’m building from your plans is anything but cheap and I’m certain it will last the better part of the next 30 years.  Great job on these plans.”

“I liked your plans and it made building a nice shed much easier. Keep up the good work.”

All Plans Include These 21 Shed Sizes

8×4 10×8 12×8
8×6 10×10 12×10
8×8 10×12 12×12
8×10 10×14 12×14
8×12 10×16 12×16
8×14 10×18 12×18
8×16 10×20 12×20

Tall Barn & Deluxe Also Includes These 10 Larger Sizes

14×16 16×16
14×20 16×20
14×24 16×24
14×28 16×28
14×32 16×32

Features Of These Sheds

Similarities:
  • Roof covering: Asphalt shingles
  • Roof structure: 2×4 trusses
  • Floor covering: 3/4 inch plywood
  • Wall materials: 4×8 sheets of hardboard siding or T-111
  • Door style: Out swinging shed door
  • Door location: Can be located any where on any wall
  • Door options: Single door, double door, wider or narrower door
Differences:
  • Roof line: Gable
  • Roof pitch: 3/12, 4/12, 5/12
  • Overhang: 2, 3 1/2, 5 1/2 inch
  • Foundation: 2) Pressure treated 4×4 skids
  • Floor joists: (8 wide) 2×4 at 16 inch O.C. (10/12 wide) 2×6 at 16 inch O.C.
  • Wall stud spacing: 2×4 at 24 inch O.C.
  • Wall framing: Single top and bottom plates with double corner studs
  • Roof line: Gable
  • Roof pitch: 6/12 or 12/12
  • Overhang: About 12 inchs
  • Foundation: 3-5) Pressure treated 4×4 skids
  • Floor joists: 2×6 at 12 inch O.C.
  • Wall stud spacing: 2×4 at 16 inch O.C.
  • Wall framing: Double top and single bottom plates with double corner studs
  • Door options: Frame for pre-hung doors and windows
  • Roof line: Gambrel (barn style)
  • Roof pitch: Combination of 29/12 lower section, 4/12 upper section
  • Overhang: About 12 inches
  • Foundation: 3-5) Pressure treated 4×4 skids
  • Floor joists: 2×6 at 12 inch O.C.
  • Wall stud spacing: 2×4 at 16 inch O.C.
  • Wall framing: Double top and single bottom plates with double corner studs
  • Door options: Frame for pre-hung doors and windows
General notes:

The biggest difference between these shed plans is the roof line. All sheds can be built with roof trusses and wall studs 16 or 24 inch O.C. and floor joists 12 or 16 inch O.C. and use 2 to 5 skids in the foundation. Either shed can be built taller or shorter and doors installed anywhere on the shed.

This is the easiest shed to build because it uses a simple truss design and small but easy to build overhang options.

These sheds look great!

And the higher roof pitches offer additional overhead storage in an easy to build loft area.

The barn style shed is very tall and might block yours or your neighbors views.

However if you can manage the barn style shed looks great and provides lots of additional storage if you build the optional loft.

Dimensions

Overall outside height at peak, not including foundation. For foundation add 4″ for skids and 2″ to 4″ for concrete blocks.
Standard 3/12 pitch

  • 8 ft wide: 8′
  • 10 ft wide: 8′ 3″
  • 12 ft wide: 8′ 6″

Standard 7ft sidewall height

  • 8 ft wide: 9′
  • 10 ft wide: 9′ 3″
  • 12 ft wide: 9′ 6″

Optional 8ft sidewall height

You can make this shed shorter if necessary by removing the same amount from all vertical cut dimensions.

12/12 pitch

  • 8 ft wide: 12′
  • 10 ft wide: 13′
  • 12 ft wide: 14′
  • 14 ft wide: 15′
  • 16 ft wide: 16′

6/12 pitch

  • 8 ft wide: 10′
  • 10 ft wide: 10.5′
  • 12 ft wide: 11′
  • 14 ft wide: 11.5′
  • 16 ft wide: 12′

These dimensions are for standard 8ft side wall height using optimal stud length.

Add 5″ if you use the maximum stud length option.

  • 8 ft wide: 12′
  • 10 ft wide: 13′
  • 12 ft wide: 14′

These dimensions are for standard 8ft side wall height using optimal stud length.

Add 5″ if you use the maximum stud length option.

Minimum inside wall height under end of truss
  • 76 1/2″ for standard 7ft side wall height
  • 88 1/2″ for optional 8ft side wall height
  • 90″ for optimal side wall height
  • 95″ for maximum side wall height
  • 90″ for optimal side wall height
  • 95″ for maximum side wall height

Buy Now

3 column middle

Buy Now 3 column middle

$7.95

3 column middle

Buy Now 3 column middle

$9.95

3 column middle

Buy Now 3 column middle

$9.97

Table of contents

Step by step instructions
  • Videos
  • Getting Started
  • Step 1: Foundation
  • Step 2: Floor
  • Step 3: Trusses
  • Step 4: Frame Walls
  • Step 5: Frame Door
  • Step 6: Raise Walls
  • Step 7: Finish Door
  • Step 8: Frame Roof
  • Step 9: Trim
  • Step 10: Shingle Roof
  • Maintenance
  • Build a ramp
  • How To Contact Me
  • General notes
  • Step 1: Foundation
  • Step 2: Floor, wood
  • Step 2a: Floor, concrete
  • Step 3: Trusses
  • Step 4: Walls
  • Step 5a: Prehung doors and windows
  • Step 5b: Single shed door
  • Step 5c: Double shed door
  • Step 5d: Open the shed door
  • Step 6: Frame and sheet the roof
  • Step 7: Trim
  • Step 8: Shingle the Roof
  • Step 9: Paint and maintenance
  • Build a loft
  • Build a ramp
  • How to contact me
  • General notes
  • Step 1: Foundation
  • Step 2: Floor, wood
  • Step 2a: Floor, concrete
  • Step 3: Trusses
  • Step 3a: Adding overhang
  • Step 3b: Adding a crows beak
  • Step 4: Walls
  • Step 5a: Prehung doors and windows
  • Step 5b: Single shed door
  • Step 5c: Double shed door
  • Step 5d: Open the shed door
  • Step 6: Frame and sheet the roof
  • Step 7: Trim
  • Step 8: Shingle the Roof
  • Step 9: Paint and maintenance
  • Build a loft
  • Build a ramp
  • How to contact me
Dimensions and Quantities Tables
  • Table 1: Materials list and cost estimate worksheet
  • Table 2: Dimensions that vary with the length and width of the shed
  • Table 3: Number of pieces to cut
  • Table 1: Materials list and cost estimate worksheet for 8×4 through 12×20
  • Table 1a: Materials list and cost estimate worksheet for 14×16 through 16×32
  • Table 1: Notes
  • Table 1a: Notes
  • Table 2: Dimensions that vary with the length and width of the shed
  • Table 2: Notes
  • Table 3: Number of pieces to cut
  • Table 4: Nailing Schedule
  • Table 5: Truss dimensions 6/12 & 12/12 pitch
  • Table 5: Notes
  • Table 1: Materials list and cost estimate worksheet
  • Table 2: Dimensions that vary with the length and width of the shed
  • Table 3: Number of pieces to cut
  • Table 4: Nailing Schedule
Building Details and Figures
  • Figure 1: Detailed view of framing
  • Figure 2: Floor dimensions and layout
  • Figure 3: Simple jig, truss components
  • Figure 4a: Gable end wall layout showing stud spacing and bottom siding overhang
  • Figure 4b: Front cross section showing 14 degree angle on sidewall studs
  • Figure 4c: sidewall stud spacer detail
  • Figure 4d: Sidewall layout showing stud spacing and siding overhang
  • Figure 5a: Outer door frame including sandwiched header
  • Figure 5b: Inner door frame
  • Figure 5c: Nailing sequence
  • Figure 5d: Chalk lines
  • Figure 5e: Complete door trim showing 7/16 inch gap between inner and outer door trim
  • Figure 6: Wall dimensions and layout
  • Figure 7: First router cut
  • Figure 8: Sidewall cross section with truss layout
  • Figure 8a: Sidewall cross section with optional overhang
  • Figure 9: Trim
  • Figure 1.1, Skid spacing
  • Figure 1.2, Concrete block spacing
  • Figure 2.1, Floor dimensions
  • Figure 2.2, Rim joist splice for floor over 20ft
  • Figure 2.3, Floor frame complete
  • Figure 3.1, Truss dimensions
  • Figure 3.2, Truss jig
  • Figure 3.3, Extra braces for 14 & 16 wide trusses
  • Figure 3.4, Finished truss comparison… 6/12 vs 12/12 pitch
  • Figure 3.5, Gable end blocking
  • Figure 3.6, Frame a loft door into the gable end
  • Figure 3.7, Template for 6/12 pitch
  • Figure 4.1, Wall dimensions
  • Figure 4.2, Wall layout
  • Figure 4.3, End wall framing
  • Figure 4.4, Side wall framing
  • Figure 5a, Frame for prehung doors and windows
  • Figure 5b.1, Outer door frame
  • Figure 5b.2, Inner door frame
  • Figure 5b.3, Complete single door frame
  • Figure 5b.4, Nailing sequence
  • Figure 5b.5, Chalk lines, cut lines
  • Figure 5b.6, Inner door trim
  • Figure 5b.7, Complete door trim showing 7/16 inch gap between inner and outer trim
  • Figure 5c.1, Inner door uprights, siding breaks, and cripple stud spacing
  • Figure 5c.2, Inner door spacers and uprights
  • Figure 5c.3, Door trim spacing and underlying cut lines
  • Figure 5c.4, Complete door trim
  • Figure 6.1, Roof framing details
  • Figure 1.1, Skid spacing
  • Figure 1.2, Concrete block spacing
  • Figure 2.1, Floor dimensions
  • Figure 2.2, Rim joist splice for floor over 20ft
  • Figure 2.3, Floor frame complete
  • Figure 3.1, Truss dimensions
  • Figure 3.2, Truss jig
  • Figure 3.3, Gambrel end framing
  • Figure 3.4, Overhang details
  • Figure 3.5, Truss comparison
  • Figure 3.6, Crows beak dimensions
  • Figure 3.7, Crows beak framing detail
  • Figure 3.8, Crows beak sheeting detail
  • Figure 4.1, Wall dimensions
  • Figure 4.2, Wall layout
  • Figure 4.3, End wall framing
  • Figure 4.4, Side wall framing
  • Figure 5a, Frame for prehung doors and windows
  • Figure 5b.1, Outer door frame
  • Figure 5b.2, Inner door frame
  • Figure 5b.3, Complete single door frame
  • Figure 5b.4, Nailing sequence
  • Figure 5b.5, Chalk lines, cut lines
  • Figure 5b.6, Inner door trim
  • Figure 5b.7, Complete door trim showing 7/16 inch gap between inner and outer trim
  • Figure 5c.1, Inner door uprights, siding breaks, and cripple stud spacing
  • Figure 5c.2, Inner door spacers and uprights
  • Figure 5c.3, Door trim spacing and underlying cut lines
  • Figure 5c.4, Complete door trim
  • Figure 6.1, Roof framing details
Options
  • Foundation for building a shed without a floor
  • Build on a concrete slab
  • Single and double doors
  • 3/12, 4/12 and 5/12 roof pitch
  • 7 or 8ft side wall height
  • 2, 3 1/2 or 5 1/2 inch overhang
  • Foundation for building a shed without a floor
  • Build on a concrete slab
  • Single or double shed doors
  • Frame for pre hung doors and windows
  • 4 ft wide loft
  • 6/12 or 12/12 roof pitch
  • Customize your overhang dimensions
  • Screened eave ventilation
  • Foundation for building a shed without a floor
  • Build on a concrete slab
  • 12 Inch (custom) overhang on all 4 sides
  • (Decorative) Crows Beak
  • Single or double shed doors
  • Frame for pre hung doors and windows
  • Full width loft
  • Screened eave ventilation
Total page count
About 90 pages About 90 pages About 80 pages

Buy Now

3 column bottom

Buy Now 3 column bottom

$7.95

3 column bottom

Buy Now 3 column bottom

$9.95

3 column bottom

Buy Now 3 column bottom

$9.97

Real Time Analytics
